Himiway

A7 PRO (FULL SUSPENSION MID-DRIVE)

A7 PRO (FULL SUSPENSION MID-DRIVE)

In stock

Regular price
Price: $2,599.00
Regular price
List Price: $3,200.00
Sale price
Price: $2,599.00
You Save: $601.00 (19%)
Color
View Cart

See Limitations

Great reasons to buy from us:

  • Image of  trustbadges Veteran Owned
  • Image of  trustbadges 2 Year Warranty
  • Image of  trustbadges Free shipping over 250 USD

Mid-Drive Muscle. Full-Suspension Comfort. Zero Compromise.

The A7 Pro is the flagship mid-drive commuter in our lineup—and it earns that spot. A 500W ANANDA mid-drive motor with 130Nm of hill-crushing torque pulls directly through your Shimano 9-speed drivetrain, giving you mechanical leverage over grades that make hub motors whine and stall. Paired with a plush SR-Suntour 120mm front fork, DNM rear air shock, 100mm handlebar-actuated dropper seatpost, and puncture-resistant Schwalbe Super Moto-X tires. Powered by a 720Wh Samsung/LG battery pack for up to 50 miles per charge (depending on assist level, terrain, and rider weight). Low-step frame for riders 5'3" to 6'5". Class 1/2/3 selectable.

Who's This For

Do you commute through a city with steep, punishing hills where hub motors bog down halfway up? Looking for a daily commuter that actually protects your lower back and wrists from jarring potholes and cracked pavement? Want the confidence of a dropper seatpost so you can drop your saddle and plant both feet flat at red lights without dismounting?

What you can do:

  • Conquer 12%+ sustained urban grades using 130Nm of mid-drive torque routed through 9 mechanical gears
  • Drop your saddle instantly at red lights with the handlebar-mounted 100mm dropper post—both feet flat, zero tipping
  • Float over potholed city streets with a 120mm SR-Suntour hydraulic fork and DNM 4-bar linkage rear air shock
  • Stop on a dime in wet or dry conditions with Shimano MT200 dual-piston hydraulic disc brakes and 180mm rotors
  • Lock the rear wheel in 2 seconds with the integrated frame café lock for quick coffee shop errands
  • Roll with high-speed puncture resistance and superior cornering grip on 27.5" × 2.4" Schwalbe Super Moto-X tires
  • Ride up to 50 miles per charge backed by genuine 720Wh Samsung/LG 21700 lithium cells

What This Bike Actually Solves

Hub Motors Overheat on Steep City Grades

The Problem: Hub motors push directly against the rear axle. On steep hills, the motor lacks mechanical leverage, drawing peak amperage, overheating, and losing speed until you're forced to pedal a 75-lb bike unassisted.

The Solution: The A7 Pro's 500W ANANDA mid-drive pulls through the bike's 9-speed Shimano chain and cassette. By downshifting into a lower gear, the motor spins in its optimal efficiency zone, applying 130Nm of torque to scale steep grades without straining.

Potholes and Expansion Joints Punish Commuter Spines

The Problem: Rigid and front-suspension commuters transfer road shock straight through the rear wheel into the seatpost, causing lower back fatigue on daily urban rides.

The Solution: True dual suspension combines 120mm of front travel with a DNM multi-link rear shock. Paired with high-volume Schwalbe tires, pavement vibration is absorbed before it reaches your body.

Awkward Dismounting at Crowded Traffic Intersections

The Problem: High commuter saddles optimized for leg extension leave riders on their tiptoes at stoplights, creating instability on slick crosswalk paint.

The Solution: An integrated 100mm dropper seatpost drops your saddle with a thumb lever. You plant both feet flat on the pavement while stopped, then pop the saddle back to full pedaling height when the light turns green.

Real-World Urban Commuter Scenarios

The Downtown Hill Climb

It's 8:15 AM. You face the steepest 4-block climb on your route to the office. While hub-motor riders are standing on their pedals or walking, you shift into 3rd gear. The 130Nm torque sensor matches your effort instantly. You cruise up at 16 MPH without breaking a sweat through your work shirt.

The Win: Arrive at morning meetings refreshed and on time, not drenched in sweat.

The Coffee Stop & Red Light Stride

You stop for an espresso on the way home. Instead of untangling a heavy U-lock for a 3-minute errand, you click the integrated frame ring lock shut. Back on the street, you hit three consecutive red lights. Each time, you hit the dropper post, drop the saddle, and sit comfortably with both feet flat on the ground.

The Win: Zero-effort errand security and effortless stoplight stability in city traffic.

A7 Pro vs. A7: What the Pro Upgrade Buys You

Component A7 Pro (This Model — $2,599) Standard A7 (Base Model — $1,899)
Motor Architecture 500W ANANDA M100 Mid-Drive 750W Rear Hub Motor
Torque Output 130Nm (Geared Mechanical Leverage) 70Nm (Direct to Axle)
Front Suspension SR-Suntour X1-BOOST 120mm Hydraulic Standard Hydraulic 120mm
Rear Suspension DNM AO-06 4-Bar Linkage Air Shock Basic 4-Link Hydraulic Shock
Tires Schwalbe Super Moto-X 27.5" × 2.4" Kenda 27.5" × 2.4"
Drivetrain Shimano Alivio 9-Speed (11-34T) Shimano Altus 8-Speed (13-32T)
Seatpost 100mm Handlebar Dropper Post Rigid Aluminum Seatpost
Integrated Frame Lock Integrated Rear Wheel Café Ring Lock Not Included
Overall Weight 77 lbs (7 lbs Lighter) 84 lbs

The Pro Advantage: Mid-drive motor architecture that delivers nearly double the torque through the gears (130Nm vs. 70Nm), premium German Schwalbe puncture-resistant tires, Shimano Alivio 9-speed, a 100mm dropper post for zero-effort stoplight stability, an integrated café wheel lock, dual UL 2849/2271 lab certifications, and a lighter 77-lb chassis. (If your route is mostly flat and you need 400 lbs payload, the base A7 is a great value; if your commute has grades over 8%, the A7 Pro's mid-drive is essential).

Looking for complete engineering measurements, detailed component specs, unboxing contents, or statutory CPSC/UL compliance records? See the collapsible rows below.


A7 PRO (FULL SUSPENSION MID-DRIVE)

MECHANICAL ADVANTAGE ON 12%+ GRADES

130Nm ANANDA Mid-Drive & Shimano 9-Speed

Standard hub motors struggle on steep city hills because they drive directly against the axle without gearing. The A7 Pro's 500W ANANDA mid-drive motor routes 130Nm of torque through the 9-speed Shimano chain and cassette, allowing you to downshift and let mechanical leverage conquer sustained hills effortlessly.

A7 PRO (FULL SUSPENSION MID-DRIVE)

TRUE DUAL-SUSPENSION ROAD ISOLATION

SR-Suntour 120mm Fork & DNM Rear Air Shock

Daily commuting shouldn't punish your spine. The A7 Pro pairs an SR-Suntour 120mm front hydraulic fork with a DNM four-bar linkage rear air shock and high-volume Schwalbe Super Moto-X tires. Potholes, streetcar tracks, and expansion joints are absorbed at the wheels, leaving you fresh for your day.

A7 PRO (FULL SUSPENSION MID-DRIVE)

DESIGNED FOR EFFORTLESS DAILY COMMUTES

Handlebar Dropper Post & Integrated Frame Lock

Drop your saddle 100mm with a thumb lever to plant both feet flat on the ground at traffic lights, then return to full pedaling height when the light turns green. When you stop for a quick coffee, click the integrated frame ring lock shut to immobilize the rear wheel in seconds.

SPECIFICATIONS & COMPLIANCE

Know Before You Buy: Specs, Laws & Assembly

E-Bike Class Flexibility & CPSC Compliance

Federal & Statutory E-Bike Classification

The Himiway A7 Pro is a dual-configuration electric bicycle engineered to satisfy federal, state, and municipal regulations across North America under 15 U.S.C. § 2085 (Low-Speed Electric Bicycles). It conforms to the Consumer Product Safety Commission standard 16 CFR Part 1512 for mechanical bicycle integrity and braking reliability.

  • Factory Default (Class 2): Ships with a thumb throttle and pedal-assist operating up to 20 MPH. Permitted on multi-use paths, bike lanes, and city streets in Texas under Transp. Code § 551.102.
  • Commuter Mode (Class 3): Riders can configure the high-contrast display to Class 3 pedal-assist mode (up to 28 MPH cadence-assisted, throttle restricted to 20 MPH) for rapid road commuting.
  • Path Restricted (Class 1): The throttle can be physically detached or electronically locked via display settings to operate as a pure Class 1 e-bike for strict municipal rail-trail networks.

Safety & Battery Laboratory Standards

Every electrical component on the A7 Pro conforms to stringent fire and electrical safety standards: ANSI/CAN/UL 2849 for drive systems, motor controllers, and integrated wiring harnesses, and UL 2271 for the 720Wh Samsung/LG lithium-ion battery pack. Equipped with Shimano MT200 hydraulic disc brakes with integrated motor cut-off sensors.

Real-World Range & Battery Safety

Real-World Range Estimates

The A7 Pro's 48V 15Ah (720Wh) internal Samsung/LG battery delivers predictable, verified commuter range across varied urban terrain. Because the mid-drive motor drives through the mechanical gears, rider cadence and gear selection directly impact efficiency:

  • Eco Mode (PAS 1): 45 to 50 miles on flat to rolling city pavement with steady pedaling cadence.
  • Standard Commute (PAS 2–3): 35 to 45 miles across urban stops, slight elevation changes, and headwinds.
  • Hill Climb & Boost (PAS 4–5): 25 to 35 miles of sustained high-torque climbing on 8%–14% urban grades.
  • Pure Throttle: 25 to 32 miles of effortless non-pedaling transit at up to 20 MPH.

Battery Longevity & Cold Weather Best Practices

To maximize cell health over its 800+ charge cycles: Never charge a freezing battery pack. Always bring the detachable pack indoors and allow it to reach room temperature (~65°F–75°F) before connecting the 3.0A fast charger. For seasonal storage, maintain charge between 50% and 70% in a dry, climate-controlled space.

Technical Specifications & Key Specs

Technical Specifications Summary

  • Motor: 500W ANANDA M100 Mid-Drive Motor (130Nm Hill-Climbing Torque)
  • Battery: 48V 15Ah (720Wh) Samsung/LG 21700 Lithium-Ion Cells (UL 2271)
  • Drivetrain: Shimano Alivio 9-Speed Rapidfire Shifter & Rear Derailleur
  • Front Suspension: SR-Suntour 120mm Travel Hydraulic Suspension Fork with Lockout
  • Rear Suspension: DNM 4-Bar Linkage Air Shock Absorber
  • Seatpost: 100mm Travel Handlebar-Actuated Dropper Seatpost
  • Braking System: Shimano MT200 Hydraulic Disc Brakes, 180mm Front & Rear Rotors
  • Tires: 27.5" × 2.4" Schwalbe Super Moto-X Puncture-Resistant Commuter Tires
  • Security: Integrated Heavy-Duty Frame-Mounted Café Ring Lock
  • Weight & Payload: 77.0 lbs total bike weight | 300 lbs maximum total payload capacity

Frame Geometry & Sizing Dimensions

  • Recommended Rider Height: 5'3" to 6'5" (Step-thru ergonomic cockpit)
  • Standover Height: 21.6 inches (Ultra-low step-through clearance)
  • Total Bike Length: 74.0 inches | Wheelbase: 48.0 inches
  • Handlebar Height / Width: 43.3 inches height | 27.6 inches width
  • Adjustable Saddle Height: 31.5 inches minimum to 39.4 inches maximum (plus 100mm dropper range)

What's Included in the Box

What's Included in the Box

Your Himiway A7 Pro arrives 85% pre-assembled in heavy-duty reinforced packaging. Setup takes approximately 20 to 35 minutes using the included custom tool set.

  • 1x Himiway A7 Pro E-Bike: Pre-assembled frame with ANANDA M100 mid-drive, SR-Suntour fork, and DNM rear air shock.
  • 1x 48V 15Ah Samsung/LG Battery Pack: Integrated down-tube pack with 2 stainless steel security keys.
  • 1x 48V 3.0A Fast Smart Charger: UL-certified fast charger with auto-shutoff (~5 hours full charge).
  • 1x 100mm Dropper Seatpost: Handlebar-actuated hydraulic dropper post pre-routed and installed.
  • 1x Integrated Frame Café Lock: Frame-mounted rear wheel immobilizer with dedicated keys for quick stops.
  • 1x 16-in-1 Multi-Tool Kit: All required Allen keys, pedal wrench, and socket attachments.
  • Full-Coverage Fenders & Rear Rack: Heavy-duty aluminum alloy fenders and integrated rear cargo rack.
  • Integrated 120-Lux Headlight & Auto-Brake Taillight: Pre-wired lighting system powered directly from main battery.

Assembly Video & Pathfinder Support

Follow along with the official step-by-step unboxing and assembly guide: Official Himiway A7 Pro Assembly Video Guide. Every bike sold by Pathfinder Pedal includes our 2-Year Limited Electrical Warranty and direct San Antonio customer support.
